MPSL-7MF Portable Handheld Pneumatic Pressure Source

1.Product Overview

The MPSL-7MF portable handheld pneumatic pressure source is a pressure calibration device independently developed by our company. It uses a manual pump to generate pressure and has the advantages of easy portability and simple operation. The internal pneumatic pressure generation device uses air as the pressure transmission medium to generate vacuum or pneumatic pressure. It is easy to operate and highly stable, making it particularly suitable as a pneumatic pressure source for various instrument calibrations. It is equipped with twoM20×1.5 female thread quick connectors for user use.

MPSL-7MFPortableHandheld Pneumatic Pressure SourceAll technical indicators comply with the technical requirements of "JB/T599-2005 Pressure Gauge Calibrator".

This product is suitable for industries such as petroleum, chemical, electric power, metallurgy, metrology, national defense, and manufacturing. It can provide stable pressure for on-site and laboratory calibration of pressure gauges, pressure transmitters, pressure switches, pressure sensors, etc.

2. Product Features

1. Open structure, with stainless steel and hard aluminum alloy components.

2. Simple structure, labor-saving and quick.

3. The booster pump adopts spiral pressurization, the piston does not rotate during pressurization, friction is small, and pressurization is fast and labor-saving.

4. High reliability, not easy to leak, national defense military quality.

5. Suitable for calibration of pressure instruments such as pressure gauges, pressure transmitters, pressure switches, pressure sensors, etc.

6. The fine adjustment valve has a wide adjustment range, stable pressure rise and fall, and high precision.

III. Technical Specifications

Working environment: working temperature (10~50) ℃ ; relative humidity:＜95% RH, non-condensing

Occurrence pressure: (-0.095-7) MPa (at standard atmospheric pressure)

Stability:0.025%

Medium: air

Pressure interface:M20×1.5 (two pressure output interfaces)

Dimensions: 280×220×170 (mm)

Weight: about 5 kg
